Description
The M-10X is Luxman’s flagship solid state power amplifier, built around its LIFES 1.0 feedback circuit. A 1,250 VA transformer and 80,000 uF of filter capacitance let it double its output as impedance halves, all the way down to 1 ohm. It can run in stereo or as a bridged mono amplifier, and it shows output on large backlit needle meters.
Highlights
- 150 watts per channel into 8 ohms, 300 watts per channel into 4 ohms
- 600 watts into 8 ohms in bridged mono mode
- Class A operation up to the first 12 watts
- LIFES 1.0 feedback with a four by two paralleled Darlington push pull output stage
- Damping factor of 600 and a 117 dB signal to noise ratio
- Balanced and RCA inputs, plus trigger connection
- Cast iron feet and loop less chassis; weighs 48.4 kg (about 107 lb)
Hear it in our Cornwall showroom by appointment.
